規(guī)格(mm)
|
相領兩測量面垂直度 |
測量面直線度 |
相對測量面平行度 |
|||
|
精度等級um |
||||||
|
00 |
0 |
00 |
0 |
00 |
0 |
|
|
160 |
2 |
4 |
>0.8 |
>1.7 |
2 |
4 |
|
200 |
2 |
4 |
0.9 |
1.8> |
2 |
4 |
|
250 |
2.2 |
4.5 |
1 |
2 |
2.2 |
4.5 |
|
315 |
2.6 |
5.2 |
1.1 |
2.3 |
2.6 |
5.5 |
|
400×400 |
3 |
6 |
1.3 |
2.6 |
3 |
6 |
|
500×500 |
3.5 |
7 |
1.5 |
3 |
3.5 |
7 |
